Product Details:

Place of Origin: China
Brand Name: Printed Circuit Board
Certification: UL,ISO
Model Number: MEPCB

Payment & Shipping Terms:

Minimum Order Quantity: 1pcs
Price: 0.01-100/pcs
Packaging Details: Inner:vacuum packaging;Outer:Carton;Bigger Quantity:Pallets
Delivery Time: 4-12 Working Days
Payment Terms: T/T, Western Union, L/C, MoneyGram
Supply Ability: 20000SQM/Month
Get Best Price Contact Now

Detail Information

Material: FR4 CEM-3 Alu PTEE Copper Thickness: 0.5-10 OZ
Soldermask Color: White Black Red Blue Yellow Purple Etc. Min. Hole: 0.1mm
Min. Space: 0.15mm Max PCB Size: 1500*800mm
Board Thickness: 0.2mm-3.2mm Surface Finish: OSP HASL HASL-LF ENIG Immersion Tin Immersion Siliver
Special: Can Be Customized Impedance Control: +/- 10%
Standard: IPC-A-610 Class II-III Peelable Mask: 0.3-0.5mm
Finished Thickness Control: +/- 5% Type: Customizable, Electronic Board, Pcb/printed Circuit Board/oem Pcb
File We Can Accept: Gerber File、CAM-350、Portal、Pads 2000、CAD、ORCAD、P-CAD、CAM 2000 Contact Mail: Mkt@me-pcb.com
Skype: Angel_xingming

Product Description



Circuit Board Printing Pcb Board Prototype Customized PCB custom pcb Circuit board

When you're looking for customized PCB fabrication, it's important to work with PCB service providers who can quickly turn around your PCB design resources. These sample boards help you verify your design before you start full production, thus avoiding costly errors. Meidear PCB is a PCB manufacturer with fast response capability.

Circuit Board Printing Pcb Board Prototype Customized PCB custom pcb Circuit board 0
We Meidear PCB offer you quick and low cost PCB prototype with high quality, No MOQ.
There are various shipping methods are available for you to choose from, such as DHL,Fedex,UPS,EMS,HK post and direct flight on special line. So we can offer PCB lead time as fast as 2-3 days and if your project is urgent we can offer you 12-24 hours expedited PCB fabrication.
All of the circuit boards will be tested well before being shipped out.
PCB Technical Capacity



Item Fabrication Capabilities Remarks
Month Capability 1000 types/month
12,000 sqm/month
Layers: 1-24 layers
Board Material: Standard FR4: Shengyi, ITEQ, KB, GDM High TG: S1000-2, IT180
  Aluminum
  FPC Material
Maximum Size FR-4: 500x1100mm
  Al: 500x1500mm
  FPC: 500x1500mm
Board Thickness 0.4-10mm
Surface treatment OSP, HASL, LF-HASL, ENIG(Chem. Gold), Immersion Tin, Immersion silver, Plating hard gold, Gold fingers,Flash gold, ENEPIG
Tolerance Size of Board   CNC tolerance is ±0.2mm, v-cut tolerance is ±0.5mm
Min solder mask bridge: 0.1mm
Drill Diameter Range 0.2-6.3mm Min. Size of drill via CNC is 0.2mm. 6.3mm is maximum size.
Annular Ring ≥0.1mm(4mil) If Annular Ring is smaller but there is enough space, there is no limit for the Annular Ring size. But if there is not enough
space coupled with dense lines, the Annular Ring size should be over 0.1mm
Min hole: 0.15mm (mechanical drilling)
  0.1mm (laser drilling)
Finished Hole Size 0.2--6.20mm Because the copper will cover the surface of hole, the Finished hole size is smaller than it is in Gerber file
The Size Tolerance of Finished
Hole (CNC
±0.08mm Tolerance of Finished Hole Size is ±0.08mm. For example, if the drill in the Gerber file is 0.6mm, the finished drill will be
0.52-0.68mm on standard.
Min. Width of Legend ≥0.13mm Min. width of legend is 0.13mm, if it is smaller, the legend in the finished board will be not clear.
Minimum Height of Legend ≥0.8mm Min. height of Legend is 0.8mm, if it is smaller, the legend in the finished board will be not clear
Space between Trace and
Board Edge
≥0.2mm(8mil) Routing: the space between line and frame should be over 0.2mm. V-cut panel: the space between line and v-cut line should be over
0.4mm.
Panelization V-scoring, Tab-routing,
Tab-routing with Perforation
(Stamp Holes)
Leave min clearance of 1.6mm between boards for break-routing. For V-score panelization, set the space between boards to be zero.
Min. aperture in half-hole
technology
0.6mm Half-hole is a special technology and the min. aperture must be over 0.6 mm
Packing & Delivery


After production and testing, your PCBs will be sent to our shipping department.
To avoid shipping damage, we MeidearPCB will pack our PCBs in several steps by difference package material. Firstly, the PCB order will be packed by vacuum bubbles bag. Secondly, after vacuum package it will be packed at our special carton boxes.
Each PCB order from MeidearPCB will be delivered on time with fast lead times, 99% of our deliveries are always on-time. The fastest fabrication time is 2-3 days. There are various shipping methods available for you to choose from, such as DHL, UPS, EMS, FedEx and HK post.
