Meidear PCB Mainboard electronics circuit pcb Shenzhen Custom Printed Circuit Boards PCB
Product Details:
Place of Origin: | China |
Brand Name: | Printed Circuit Board |
Certification: | UL,ISO |
Model Number: | MEPCB |
Payment & Shipping Terms:
Minimum Order Quantity: | 1pcs |
---|---|
Price: | 0.01-100/pcs |
Packaging Details: | Inner:vacuum packaging;Outer:Carton;Bigger Quantity:Pallets |
Delivery Time: | 4-12 Working Days |
Payment Terms: | T/T, Western Union, L/C, MoneyGram |
Supply Ability: | 20000SQM/Month |
Detail Information |
|||
Material: | FR4 CEM-3 Alu PTEE | Copper Thickness: | 0.5-10 OZ |
---|---|---|---|
Soldermask Color: | White Black Red Blue Yellow Purple Etc. | Min. Hole: | 0.1mm |
Min. Space: | 0.15mm | Max PCB Size: | 1500*800mm |
Board Thickness: | 0.2mm-3.2mm | Surface Finish: | OSP HASL HASL-LF ENIG Immersion Tin Immersion Siliver |
Special: | Can Be Customized | Impedance Control: | +/- 10% |
Standard: | IPC-A-610 Class II-III | Peelable Mask: | 0.3-0.5mm |
Finished Thickness Control: | +/- 5% | Type: | Customizable, Electronic Board, Pcb/printed Circuit Board/oem Pcb |
File We Can Accept: | Gerber File、CAM-350、Portal、Pads 2000、CAD、ORCAD、P-CAD、CAM 2000 | Contact Mail: | Mkt@me-pcb.com |
Skype: | Angel_xingming |
Product Description
Meidear PCB Mainboard electronics circuit pcb Shenzhen Custom Printed Circuit Boards PCB
We Meidear PCB do OEM PCB Manufacturing Service for over 10 years,can handle various kinds of your pcb circuit boards based on your PCB Gerber Design,including multilayer circuit board,four layer pcb,pcb prototype fabrication,and no MOQ limits,we support from prototype to mass order,1-40L,any interests just send your mail to mkt@me-pcb.com.
When you're looking for customized PCB fabrication, it's important to work with PCB service providers who can quickly turn around your PCB design resources. These sample boards help you verify your design before you start full production, thus avoiding costly errors. Meidear PCB is a PCB manufacturer with fast response capability.
We Meidear PCB offer you quick and low cost PCB prototype with high quality, No MOQ.
There are various shipping methods are available for you to choose from, such as DHL,Fedex,UPS,EMS,HK post and direct flight on special line. So we can offer PCB lead time as fast as 2-3 days and if your project is urgent we can offer you 12-24 hours expedited PCB fabrication.
All of the circuit boards will be tested well before being shipped out.
There are various shipping methods are available for you to choose from, such as DHL,Fedex,UPS,EMS,HK post and direct flight on special line. So we can offer PCB lead time as fast as 2-3 days and if your project is urgent we can offer you 12-24 hours expedited PCB fabrication.
All of the circuit boards will be tested well before being shipped out.
PCB Technical Capacity
Item | Fabrication Capabilities | Remarks |
Month Capability | 1000 types/month | |
12,000 sqm/month | ||
Layers: | 1-24 layers | |
Board Material: | Standard FR4: Shengyi, ITEQ, KB, GDM High TG: S1000-2, IT180 | |
Aluminum | ||
FPC Material | ||
Maximum Size | FR-4: 500x1100mm | |
Al: 500x1500mm | ||
FPC: 500x1500mm | ||
Board Thickness | 0.4-10mm | |
Surface treatment | OSP, HASL, LF-HASL, ENIG(Chem. Gold), Immersion Tin, Immersion silver, Plating hard gold, Gold fingers,Flash gold, ENEPIG | |
Tolerance Size of Board | CNC tolerance is ±0.2mm, v-cut tolerance is ±0.5mm | |
Min solder mask bridge: | 0.1mm | |
Drill Diameter Range | 0.2-6.3mm | Min. Size of drill via CNC is 0.2mm. 6.3mm is maximum size. |
Annular Ring | ≥0.1mm(4mil) | If Annular Ring is smaller but there is enough space, there is no limit for the Annular Ring size. But if there is not enough space coupled with dense lines, the Annular Ring size should be over 0.1mm |
Min hole: | 0.15mm (mechanical drilling) | |
0.1mm (laser drilling) | ||
Finished Hole Size | 0.2--6.20mm | Because the copper will cover the surface of hole, the Finished hole size is smaller than it is in Gerber file |
The Size Tolerance of Finished Hole (CNC |
±0.08mm | Tolerance of Finished Hole Size is ±0.08mm. For example, if the drill in the Gerber file is 0.6mm, the finished drill will be 0.52-0.68mm on standard. |
Min. Width of Legend | ≥0.13mm | Min. width of legend is 0.13mm, if it is smaller, the legend in the finished board will be not clear. |
Minimum Height of Legend | ≥0.8mm | Min. height of Legend is 0.8mm, if it is smaller, the legend in the finished board will be not clear |
Space between Trace and Board Edge |
≥0.2mm(8mil) | Routing: the space between line and frame should be over 0.2mm. V-cut panel: the space between line and v-cut line should be over 0.4mm. |
Panelization | V-scoring, Tab-routing, Tab-routing with Perforation (Stamp Holes) |
Leave min clearance of 1.6mm between boards for break-routing. For V-score panelization, set the space between boards to be zero. |
Min. aperture in half-hole technology |
0.6mm | Half-hole is a special technology and the min. aperture must be over 0.6 mm |
